FABNET 19' Rack mount 2×32 RACK MOUNT PLC SPLITTER, LC/APC

FSPLA32

Fiber PLC Splitter is a crucial component in fiber optic networks used to divide a single optical signal into multiple signals. Allows for the efficient distribution of optical signals to multiple endpoints, which is essential in applications such as passive optical networks (PONs) and other optical distribution systems. The LC/APC splitter is equipped with PLC as per the FTTH requirement or enterprise cabling application. Splitters ensure good uniformity and low insertion loss and low polarization dependent loss.

Application

FTTH applications - Indoor or outdoor.

Specifications & Features

Used for GPON/EPON/xPON/GEPON hardware.
Bend-resistant insensitive optical fiber with the G657 A model.
Low Insertion Loss.
Specifically designed for indoor applications.
Easy installation with no special tool required.
TIA-568.3-D, ROHS.

Specifications Features

{ "Port Configuration": "2x32", "Connector/Adaptor Type": "LC/APC", "Fiber Type": "G657A1", "Operating Wavelength": "1260-1650 nm", "Insertion Loss": "17.4 dB", "Return Loss": "55 dB", "Polarization Dependent Loss": "0.3 dB", "Operating Temperature": "-20~+60 °C", "Installation": "19” Rack mount" }
