Application

Applications

• Supports Category 8 networks up to 2000MHz
• Designed to support all Class I protocols including 25/40GBASE-T
• Power Over Ethernet Plus (PoE+), High Power Ethernet (PoE++) and 4 Pair Power Over Ethernet (4PPoE)
• Data centers and backbone in structured cabling installations, high bandwidth requirement

Specifications & Features

• The cable complies with ANSI/TIA-568-D.2, ISO 11801
• Cable jacket LSZH
• 22AWG premium-grade copper conductor
• Fully shielded construction ensures virtually zero cross talk

Specifications Features

{ "Conductor": "Solid Bare Copper", "Conductor Size": "22 AWG", "Insulation": "Polyethylene", "Number of Insulated Conductors": "8, twisted in 4 pairs", "Color Code of Pairs": [ "Blue x White/Blue", "Orange x White/Orange", "Green x White/Green", "Brown x White/Brown" ], "Overall Shield": "Tinned Copper Braid", "Individual Pair Shield": "Aluminum Foil Tape", "Outer Jacket": "LSZH", "Jacket Color": "White. Other colors available upon request", "Overall Length (m)": "500mtr", "Short Term Bend Radius": "4xOD mm", "Long Term Bend Radius": "8xOD mm", "Operating Temperature": "-20 to +75C", "Installation Temperature": "0 to +50C", "Storage Temperature": "-20 to +80C", "Pulling Tension, maximum": "100 N", "Cable Outside Diameter": "8.2 mm ± 0.3 mm", "Packaging Type": "Reel" }
