Application

Applications

• 10 BASE-T (IEEE 802.3)
• 100 VG-Any LAN (IEEE 802.12)
• 4/16 Mbps Token Ring (IEEE 802.5)
• 52 Mbps ATM
• For analog and digital telecommunications systems, up to 10 M Bits including 10BaseT

Specifications & Features

• The cable complies with ANSI/TIA-568-C.2, IEC-61156-5, IEC-11801
• Cable jacket UV resistant PVC
• 24AWG premium-grade copper conductor
• RoHS & REACH compliant

Specifications Features

{ "Conductor": "Solid Bare Copper", "Conductor Size": "24 AWG (0.5mm)", "Insulation": "Polyethylene", "Number of Pairs": ["10", "25", "50", "100"], "Unit Binder": ["Unit 1 Blue", "Unit 2 Orange", "Unit 3 Green", "Unit 4 Brown", "Unit 5 Grey"], "Tape Wrapping": "Polyester Tape Coverage: 100%", "Outer Jacket": "UV resistant PVC", "Jacket Color": "RAL 7035 (Grey)", "Overall Length (m)": ["500", "1000 Mtr"], "Rip Cord": "Yes", "Operating Temperature": "-20 to +60C", "Installation Temperature": "0 to +50C", "Bending Radius": "8.0xD mm", "Storage Temperature": "-20 to +80C", "Cable Outside Diameter": [ "10 Pair-7mm", "25 Pair-10.2mm", "50 Pair-17.5mm", "100 Pair-21mm" ], "Packaging Type": "Reel" }
