Application

Applications

• Operates at wavelengths of 1310 nm and 1550 nm.
• Cables are specifically designed for indoor applications, mainly used in intra-building.

Specifications & Features

• Compliant with ANSI/TIA-568.3-D, ISO/IEC 11801
• Jacket options: LSZH, Yellow
• 900 Microns Tight buffered fibers support fast field installations.
• High Modulus, Aramid yarn as a peripheral strength member.
•    Water resistant & UV resistant

Specifications Features

{ "Fiber Type": "Single mode 9/125 G652.D", "Number of cores": "48 to 144", "Type of tube": "Tight", "Number of Tubes": "Multi", "Category": "OS2", "Strength Member": "E-glass Yarns", "Color of Fibers in Per Tube": [ "Blue", "Orange", "Green", "Brown", "Gray", "White", "Red", "Black", "Yellow", "Violet", "Pink", "Aqua", "Blue with black tracer", "Orange with black tracer", "Green with black tracer", "Brown with black tracer", "Gray with black tracer", "White with black tracer", "Red with black tracer", "Natural", "Yellow with black tracer", "Violet with black tracer", "Rose with black tracer", "Aqua with black tracer" ], "Simplex Zip cord Diameter (mm)": "2.0", "Tight Buffer Colors": "Colors and Colors with Black/White Tracer", "Outer Jacket Colors": "SM-Yellow", "Strength Element": "Swellable Glass Yarn", "Outer sheath material": "LSZH", "Outer diameter approx.": "14.5 to 24.5mm" }
