FABNET Fiber OS2 Singlemode Fire Resistant Indoor/Outdoor Single Loose tube 04 to 24 core Bulk Cable, Black

FFCS2IOFRxx

Fire-resistant single loose tube non-metallic fiber optic cables are designed for environments prone to electrical interference, such as buildings, tunnels, and subways. Suitable for areas where critical data transmission must continue when the building or structure in which it is installed is on fire.

Applications

Inside buildings, tunnels, subways, or closed areas in general, specially designed to guarantee the signal transmission even in case of fire.
Suitable for environments where rodent resistance is required also for direct burial.

Specifications & Features

Single Mode: OS2 ITU-G652D
Corrugated steel-tape armor for superior mechanical crush and impact resistance and optimum rodent protection.
Customizable fiber selection including single-mode, multimode.
Single gel-filled loose-tube to block the ingress of water.
Twin-sheath design offering additional flame-retardant material and mechanical protection.
04-24 Fiber counts – color-coded according to TIA-598-D.
Enhanced Rodent Resistance.
UV-Resistance.
Corrugated Steel Tape Armor (ECCS Tape) Thickness > 0.125mm.
Rodent Proof.

Fiber Type	Single mode 9/125 G652.D
Number of cores	04 to 24
Type of tube	Loose
Number of Tubes	Single
Category	OS2
Color of Fibers in Per Tube	Blue Orange Green Brown Gray White Red Black Yellow Violet Pink Aqua Blue with black tracer Orange with black tracer Green with black tracer Brown with black tracer Gray with black tracer White with black tracer Red with black tracer Natural Yellow with black tracer Violet with black tracer Rose with black tracer Aqua with black tracer
Core Wrapping	Water Blocking Tape
Armor	Corrugated Steel Tape
Outer Jacket	LSZH

Download Brochure - FFCS2IOFRxx
